30 years old factory,specialized in manufacturing optical drop cables and preconnectorized optical patch cords. one-stop supplier for FTTH solutions.
1 Years
| Ask Lasest Price | |
| Brand Name : | OEM |
| Model Number : | PLC Splitter |
| Certification : | CE ISO |
| Price : | case by case |
| Payment Terms : | L/C,T/T |
| Supply Ability : | 20,000 heads per day |
| Delivery Time : | 5-30days |
PLC Tap Bare Fiber Compact PLC Tap Low Insertion Loss Wide Operating Wavelengths 1x4 1x16 1x32 1x64 PLC
A PLC (Planar Lightwave Circuit) splitter is a passive optical component used in fiber optic networks to divide a single optical signal into multiple output signals.
Product Name: Ultra-Compact Bare Fiber PLC Splitter Tap (1×4 / 1×16
/ 1×32 / 1×64)
Series Model: PLC Tap Pro Series
Designed for next-generation optical networks, the Ultra-Compact Bare Fiber PLC Splitter Tap leverages high-performance Planar Lightwave Circuit (PLC) technology to enable precise signal distribution across diverse splitting configurations (1×4, 1×16, 1×32, 1×64). Tailored for demanding environments such as 5G infrastructure, hyperscale data centers, and industrial IoT systems, its minimalist bare fiber design and ultra-slim profile ensure seamless integration into tight spaces, including micro-modules, splice trays, and high-density racks.
Precision-engineered PLC chips and optimized alignment processes deliver ultra-low insertion loss (e.g., 1×4 ≤7.0dB; 1×64 ≤21.0dB), preserving signal integrity for critical applications.
Operates across 1260–1650nm wavelengths, supporting legacy systems and emerging technologies like 25G/100G PON, coherent DWDM, and LiDAR networks.
Engineered with thermally stable silica waveguide cores, the splitter maintains consistent performance in extreme conditions (-40°C to +85°C), ideal for outdoor cabinets and harsh industrial settings.
Flexible port configurations (up to 1×64) and customizable fiber lengths/connectors (optional armored or waterproof jackets) adapt to evolving network architectures.
Featherweight, compact housing (e.g., 1×64 model: 70mm×8mm×5mm) simplifies high-density installations without compromising durability or ease of maintenance.
Parameter | Performance |
|---|---|
Split Ratios | 1×4 / 1×16 / 1×32 / 1×64 |
Wavelength | 1260–1650 nm |
Insertion Loss | 1×4: ≤7.0dB; 1×16: ≤14.0dB; 1×32: ≤17.5dB; 1×64: ≤21.0dB |
Uniformity | ≤1.0dB |
PDL | ≤0.3dB |
Return Loss | ≥55dB |
Fiber Compatibility | Single-mode (G.652D, G.657.A1/B3) |
Operating Range | -40°C to +85°C (humidity: 5–95% non-condensing) |
5G Fronthaul/Midhaul: Distributed antenna systems (DAS) and cloud-RAN fiber resource optimization.
Smart City Infrastructure: Traffic monitoring, utility grids, and public safety networks.
Enterprise Cloud Edge: High-speed interconnects for colocation and edge computing nodes.
Industrial Automation: Reliable signal splitting for factory IoT and machine vision systems.
Standard Models: PLC-TAP-PRO-1x4 / 1x16 / 1x32 / 1x64
Customization: Fiber type, connectorization (LC/SC/MPO), splitter ratios, and protective coatings.
100% inspection : ISO9001 Quality management system
Packed in cartons or plastic boxes.
Q: What is the brand name of this Fiber Optic Patch Cord product?
A: The brand name of this product is OEM.
Q: What is the model number of this Fiber Optic Patch Cord product?
A: The model number is Single Fiber Or Multi Fiber Single Mode.
Q: Where is this Fiber Optic Patch Cord product manufactured?
A: This product is manufactured in Shandong, China.
Q: What certifications does this Fiber Optic Patch Cord product have?
A: This product is certified with CE and ISO.
Q: What is the minimum order quantity for this Fiber Optic Patch Cord product?
A: The minimum order quantity is 100 pieces.
|
|
